NTH MANUAL CHUCKS JIS SERIES

KM SERIES 3-JAW ADJUSTABLE PRECISION SELF-CENTERING CHUCKS

KM SERIES 3-JAW ADJUSTABLE PRECISION SELF-CENTERING CHUCKS

Click on product image magnification

Download

Online inquiry

Products in detail

Brand：NTH

Mostly suitable for the production of parts with top concentricity.lt is foruniversal use,hawever particularly advantageous for grinding machines.indexing heads and lathes
adjusting accuracy within 0.005mm
The clamped workpiece is adjusted to the required concentricity by meanof 4 radially arranged adjusting screws




单位/UNIT:mm

型式/规格
Model/Spec

最大容许扭矩
Max. Allowable Torque
kgf*m

夹持力

Gripping Force
kgf

净重
Weight
Kg

最高转速

Max speed

RPM

惯性矩I

Moment of Inertia I

Kg*m2

夹持范围外径
O.D Clamping Range
mm

夹持范围内径
I.D. Clamping Range
mm

KM-06

9.0

3300

11

4000

0.04

8-160

55-150

Subject to technology changes without prior information

Non-standard requirements can be made
